VEHICLE
-
Vehicle Dimensions: 2,200 × 810 × 1,220 mm (86 × 32 × 48 in)
-
Wheelbase: 1,380 mm (52.3 in)
-
Seat Height: 910 mm (35.8 in)
-
Minimum Ground Clearance: 315 mm (12.40 in)
-
Net Weight: 98 kg (216 lbs)
-
Maximum Load: 160 kg (353 lbs)
-
Braking System: Hydraulic Disc
-
Braking Efficiency: 3.64 / 3.09 (m/s²)
-
Rim Size: 1.6 × 21 / 2.15 × 18
-
Tire Size (CST): 70/100-21 (Front) – 90/100-18 (Rear)
-
Tire Size (Maxxis): 80/100-21 (Front) – 110/90-18 (Rear)
-
Front Fork: Dual Chamber 850 mm, 43 mm tube / 250 mm travel
-
Rear Shock: 350 mm travel / 90 mm / 500–720 lbs spring
-
Minimum Turning Radius: 2.1 m
-
Steering Angle: >45°
-
Forward Tilt Angle: 26°
POWER
-
Nominal Voltage: DC 97.2 V
-
Maximum Speed: Factory limited to 32 km/h (20 mph)
-
Peak Torque: 754 Nm
-
Peak Power: 32 kW
-
Range (at 25 km/h): 115 km (71.5 miles)
-
Power Modes: Eco / Sport / Hyper / Reverse
ELECTRONICS
-
Battery Pack: 97.2 V 45 Ah
-
Battery Cells: Samsung 50S 21700 / LG H51
-
Battery Weight: 24.5 kg (58 lbs)
-
Battery Protection Level: IP67
-
Regenerative Braking: 4-level adjustment
-
Display: TFT 320 DPI / 167° viewing angle
MOTOR
-
Motor Type: DC Permanent Magnet Synchronous
-
Mounting Position: Mid-mounted
-
Motor Cooling: Air-cooled
-
Motor Rated Torque: >14 Nm
-
Motor Peak Torque: >90 Nm
-
Motor Rated Power: 8.6 kW
TRANSMISSION
-
Primary Transmission: Gearbox
-
Drive Transmission: 520 Chain
-
Front Sprocket: 14 / 15T
-
Rear Sprocket: 50 / 53T
Important Notice:
This model is strictly sold for off-road use only and complies with federal, state, and local regulations on speed and power limits. Modifying the bike to bypass these restrictions is the buyer's responsibility, and it may result in non-compliance with applicable laws.
